Skid mounted nitrogen production unit

The principle of the nitrogen production unit is the same as that of the PSA nitrogen production machine, the only difference between the two is that the nitrogen production unit is assembled as a whole by prying. The so-called pry and install refers to fixing a set of equipment on a chassis made of angle steel or I-beam, which can be moved and positioned with the help of a pry bar. This is a way of combining equipment framework and equipment as a whole, where valves, pumps, and other equipment have been installed to form a complete assembly.

View Details

Energy saving up to 10% to 30%

For 40 years, we have been dedicated to product research and application, with multiple advanced process technologies, selection of high-quality adsorbents, and development and application of high-performance programmable valves. Compared to other Nitrogen Generator Energy savings up to 10% to 30%.
Twenty years of usage time

The entire machine is designed to last for up to 20 years

The main components such as pressure vessels, program-controlled valves, pipelines, filters, etc. have a 20-year quality guarantee
Rigorous application condition design

Under the following operating conditions, the nitrogen production equipment operates stably and continuously at full load< Environmental temperature:- 20 ℃~+50 ℃
Environmental humidity: ≤ 95%
Atmospheric pressure: 80kPa~106kPa
Note: Special design is allowed if it is not within the above operating range
Easy installation and maintenance

Compact and reasonable modern industrial design, optimized shape, fine craftsmanship, compared with other nitrogen production equipment, it has high reliability, long service life, small installation area, and easy installation and maintenance.

Product Details

Product Features

● Advanced technology and unique distributor, capable of producing qualified nitrogen gas within 5 minutes of startup, fast and convenient;
● Compact structure with modular design, small footprint and low investment, nitrogen production can be achieved with electricity, and low energy consumption;
● Unique Hurricane style molecular sieve filling method, tighter, more solid, and longer service life;
● Imported fully automatic human-machine interaction system with adjustable flow, pressure, and purity to achieve unmanned automation;

Technical Parameter

● Processing capacity -1-500Nm3/h
● Purity -99% to 99.9999%
● Pressure -0.1-0.8MPa (adjustable)
● Dew point - ≤ -40 ℃ to -70 ℃
